1. LAN interface suitable for 10/100/1000Base-TX applications
2. RJ45/USB stacked design saves on PCB real estate
3. USB module complies with USB 2.0 standards and meets CAT5 Fast Ethernet industry performance standard
4. Magnetics are 100% electrically tested for HI-POT and continuity
5. Meets or exceeds IEEE 802.3 and ANSI X3.263 standards including 350 _H minimum OCL with 8 mA bias
6. Operating temperature 0℃ TO 70℃
7. Recognized by UL 60950-1
8. Housing Material: PBT
9. Insert RJ Upper Support Material: Thermoplastic UL 94V-0
10. Insert Contact Material: Phosphor Bronze
11. Contact RJ Upper Suppor pin Material: Thermoplastic UL 94V-0
12. Contact Material: SPCC
13. Shielding Material: BRASS, C2680R-H THICKNESS , 0.25mm &
                                     STAINLESS, SUS304 THICKNESS : 0.25±0.01mm
14. USB Housing Material: Thermoplastic UL94V-0 Black
15. USB Contact Material: Phosphor Bronze
16. USB Shell Material: Copper Alloy (t=0.30mm)
17. USB Tangue Shell Material: Copper Alloy (t=0.30mm)
18. Customized design available
